a list of deployments and one in full: status, its build's log and trace
npx shadcn add @ag/deploymentAlready installed? Preview an update
npx shadcn add @ag/deployment --dry-runYour installed source stays unchanged until you update it. How updates work
- Changed:
DeploymentDetailsdraws only what the deployment carries. Before, every step's state was read off the status alone, so a deployment showed a passed summary, passed domains and waiting checks the host never reported, an empty picture, an empty settings section, and Share and Logs with nothing behind them. Now the picture is there only withpreview, the settings only withrecommendations, Share only with auniquedomain, Logs and the duration only for a build the host saw, Visit only with a domain serving it. - Changed (breaking): the steps are
DeploymentDetails' children, composed by the consumer from what it can report:DeploymentBuild(itsdefaultRunSummarymoved here fromDeploymentDetails),DeploymentSummary,DeploymentChecks, andDeploymentStep(value,title,state,aside) for any other step; each built-in one asserts its part is there, and a deployment carrying a build must showDeploymentBuild. Migration:<DeploymentDetails deployment={d} />becomes<DeploymentDetails deployment={d}><DeploymentBuild /></DeploymentDetails>, addingDeploymentSummaryandDeploymentCheckswhere the deployment hasresourcesandchecks; a domain-assignment step is aDeploymentStepwith the state your host reports.stepsOfandDeploymentStepsare gone (buildState,outputState,checksState), anddefaultOpennames sections by theirvalue. - Changed (breaking):
Deployment.buildis optional: absent, the build ran where the host could not see it (nostarted, nodurationeither). A ready or failed deployment with a build and no start now throws; pass nobuildinstead of an empty one.domainsare the hosts serving this deployment now: an older one keeps only its own address.
also called deploys, deployments, builds, ci
shelf data & status
uses accordion, avatar, badge, button, copy, log, material, menu, panel, popover, relative-time, spinner, status, telemetry, trace
the demo above, verbatim
"use client"
import { FileCode, Link2, RotateCcw } from "lucide-react"
import { useSearchParams } from "next/navigation"
import * as React from "react"
import { Sample } from "@/app/samples"
import type {
Deployment,
DeploymentState,
Domain,
Environment,
} from "@/registry/base-nova/lib/deployment-core"
import type {
Fields,
LogLevel,
LogLine,
TraceSpan,
} from "@/registry/base-nova/lib/telemetry"
import { Breadcrumb } from "@/registry/base-nova/ui/breadcrumb"
import { Button } from "@/registry/base-nova/ui/button"
import { Copy } from "@/registry/base-nova/ui/copy"
import { DeploymentList } from "@/registry/base-nova/ui/deployment"
import {
DeploymentBuild,
DeploymentChecks,
DeploymentDetails,
type DeploymentLink,
DeploymentStep,
DeploymentSummary,
} from "@/registry/base-nova/ui/deployment-details"
import { MaterialProvider } from "@/registry/base-nova/ui/material"
import type { MenuEntry } from "@/registry/base-nova/ui/menu"
// #region deployments
/** The instant the dashboard is read at: every "11h ago" is said from here. */
const NOW = Date.UTC(2026, 9, 12, 21, 40)
const MIN = 60_000
const HOUR = 60 * MIN
const svg = (body: string) =>
/** The projects, each with its favicon; ui has none, so its initial. */
const PROJECTS = {
garden: {
name: "untitled-garden",
icon: svg(
'<g fill="none" stroke="#3ecf8e" stroke-width="2.2" stroke-linecap="round" stroke-linejoin="round"><path d="M7 20h10"/><path d="M10 20c5.5-2.5.8-6.4 3-10"/><path d="M9.5 9.4c1.1.8 1.8 2.2 2.3 3.7-2 .4-3.5.4-4.8-.3-1.2-.6-2.3-1.9-3-4.2 2.8-.5 4.4 0 5.5.8z"/><path d="M14.1 6a7 7 0 0 0-1.1 4c1.9-.1 3.3-.6 4.3-1.4 1-1 1.6-2.3 1.7-4.6-2.7.1-4 1-4.9 2z"/></g>',
),
},
ui: { name: "ui" },
site: {
name: "adriangalilea-com",
icon: svg(
'<defs><radialGradient id="g" cx="35%" cy="30%" r="75%"><stop offset="0" stop-color="#d1fae5"/><stop offset=".45" stop-color="#2dd4a4"/><stop offset="1" stop-color="#065f46"/></radialGradient></defs><circle cx="12" cy="12" r="10" fill="url(#g)"/>',
),
},
tempo: {
name: "tempo",
icon: svg(
'<rect x="1" y="1" width="22" height="22" rx="5" fill="#fff"/><path d="M7 5h10M7 19h10M8 5c0 4.5 8 5 8 7s-8 2.5-8 7M16 5c0 4.5-8 5-8 7s8 2.5 8 7" fill="none" stroke="#000" stroke-width="1.6" stroke-linecap="round"/>',
),
},
} as const
const AUTHORS = {
adrian: { name: "adriangalilea", avatar: "/adriangalilea.jpg" },
neil: { name: "narmstrong", avatar: "/apollo-11/armstrong.png" },
buzz: { name: "buzzaldrin", avatar: "/apollo-11/aldrin.png" },
} as const
type Project = (typeof PROJECTS)[keyof typeof PROJECTS]
/** A build's steps, ms from its start, with what each wrote: when, level, words, and
* `true` when the line says a step succeeded. One script for every build: a build
* of another length is the same build, each instant scaled to it. */
type Said = readonly [number, LogLevel, string, true?, Fields?]
interface Step {
id: string
parent?: string
name: string
service: string
from: number
to: number
error?: true
said: readonly Said[]
}
/** How long the script runs, ms. */
const SCRIPT_MS = 91_000
const steps = (repo: string, branch: string, sha: string): Step[] => [
{
id: "clone",
parent: "build",
name: "clone",
service: "git",
from: 0,
to: 1_100,
said: [
[0, "info", "Running build in Washington, D.C., USA (East), iad1"],
[20, "info", "Build machine configuration: 4 cores, 8 GB"],
[
60,
"info",
`Cloning github.com/adriangalilea/${repo} (Branch: ${branch}, Commit: ${sha})`,
],
[1_090, "info", "Cloning completed: 1.031s", true],
],
},
{
id: "restore",
parent: "build",
name: "restore build cache",
service: "cache",
from: 1_200,
to: 6_400,
said: [
[1_250, "info", "Restoring build cache from previous deployment"],
[6_380, "info", "Restored build cache (512.8 MB)", true],
],
},
{
id: "cli",
parent: "build",
name: "vercel build",
service: "vercel",
from: 6_500,
to: 78_400,
said: [
[6_600, "info", 'Running "vercel build"'],
[6_800, "info", "Vercel CLI 48.6.0"],
],
},
{
id: "install",
parent: "cli",
name: "pnpm install",
service: "pnpm",
from: 7_300,
to: 21_800,
said: [
[7_400, "info", "Installing dependencies..."],
[
9_100,
"warn",
"WARN deprecated subdependencies found: glob@7.2.3, inflight@1.0.6",
],
[
12_000,
"warn",
"WARN Issues with peer dependencies found: @types/react 19.2 wanted by 2 packages, 19.1 found",
],
[
21_700,
"info",
"Packages: +1204, done in 14.9s",
true,
{ added: 1204, reused: 1198, downloaded: 6 },
],
],
},
{
id: "next",
parent: "cli",
name: "next build",
service: "next",
from: 21_900,
to: 78_400,
said: [
[22_000, "info", "Detected Next.js version: 16.0.3"],
[22_100, "info", 'Running "pnpm run build"'],
[78_350, "info", "Build Completed in /vercel/output [57s]", true],
],
},
{
id: "compile",
parent: "next",
name: "compile",
service: "next",
from: 22_600,
to: 61_800,
said: [
[22_700, "info", "Creating an optimized production build ..."],
[
48_000,
"warn",
"Compiled with warnings: ./app/blog/page.tsx: Critical dependency: the request of a dependency is an expression",
],
[61_700, "info", "Compiled successfully in 39.1s", true],
],
},
{
id: "types",
parent: "next",
name: "check types",
service: "next",
from: 61_900,
to: 68_200,
said: [
[62_000, "info", "Linting and checking validity of types ..."],
[68_100, "info", "Types checked", true],
],
},
{
id: "collect",
parent: "next",
name: "collect page data",
service: "next",
from: 68_300,
to: 71_200,
said: [
[68_400, "info", "Collecting page data ..."],
[
70_100,
"warn",
"Unsupported metadata themeColor is configured in metadata export in /. Please move it to viewport export instead.",
],
],
},
{
id: "generate",
parent: "next",
name: "generate static pages",
service: "next",
from: 71_300,
to: 76_600,
said: [
[71_400, "info", "Generating static pages (0/96) ..."],
[74_000, "info", "Generating static pages (48/96)"],
[76_500, "info", "Generating static pages (96/96)", true],
],
},
{
id: "finalize",
parent: "next",
name: "finalize",
service: "next",
from: 76_700,
to: 78_300,
said: [
[76_800, "info", "Finalizing page optimization ..."],
[
77_900,
"warn",
"Using edge runtime on a page currently disables static generation for that page",
],
[78_200, "info", "Collecting build traces ..."],
],
},
{
id: "deploy",
parent: "build",
name: "deploy outputs",
service: "vercel",
from: 78_500,
to: 84_300,
said: [
[78_600, "info", "Deploying outputs..."],
[
84_200,
"info",
"Deployment completed",
true,
{ region: "iad1", functions: 14, static: 1204 },
],
],
},
{
id: "upload",
parent: "build",
name: "upload build cache",
service: "cache",
from: 84_400,
to: 91_000,
said: [
[84_500, "info", "Creating build cache..."],
[87_100, "info", "Created build cache: 2.6s"],
[87_200, "info", "Uploading build cache [312.45 MB]..."],
[90_900, "info", "Build cache uploaded: 3.7s", true],
],
},
]
/** The same build, failing where its types are checked: what runs after never
* starts, and every span it failed inside fails with it. */
const failing = (repo: string, branch: string, sha: string): Step[] =>
steps(repo, branch, sha)
.filter((s) => s.from < 61_900 || s.id === "types" || s.id === "next")
.map((s) =>
s.id === "types"
? {
...s,
to: 64_900,
error: true,
said: [
[62_000, "info", "Linting and checking validity of types ..."],
[64_800, "error", "Failed to compile."],
[
64_850,
"error",
"./app/player/chapters.tsx:42:17\nType error: Property 'poster' does not exist on type 'ChapterProps'.",
undefined,
{ file: "app/player/chapters.tsx", line: 42, column: 17 },
],
],
}
: s.id === "cli"
? { ...s, to: 64_960, error: true }
: s.id === "next"
? {
...s,
to: 64_950,
error: true,
said: [
...s.said.slice(0, 2),
[
64_940,
"error",
'Error: Command "pnpm run build" exited with 1',
],
],
}
: s,
)
/** A build of `duration` ms that began at `started`, as lines and spans on its clock;
* a failing one ends where it failed (`failedAt`, ms of the script). */
function buildOf(
id: string,
started: number,
duration: number,
script: Step[],
): NonNullable<Deployment["build"]> {
const end = Math.max(...script.map((s) => s.to))
const at = (ms: number) => started + Math.round((ms * duration) / end)
const failed = script.some((s) => s.error)
const spans: TraceSpan[] = [
{
id: "build",
name: "build",
service: "vercel",
from: started,
to: started + duration,
status: failed ? "error" : "ok",
},
...script.map((s) => ({
id: s.id,
parentId: s.parent,
name: s.name,
service: s.service,
from: at(s.from),
to: at(s.to),
status: s.error ? ("error" as const) : ("ok" as const),
})),
]
const lines: LogLine[] = script
.flatMap((s) =>
s.said.map(([ms, level, message, ok, fields]) => ({
at: at(ms),
level,
message,
verb: ok ? ("success" as const) : undefined,
fields,
span: { id: s.id, name: s.name },
})),
)
.sort((a, b) => a.at - b.at)
.map((line, n) => ({ id: `${id}-${n}`, ...line }))
return { lines, spans }
}
/** The domains serving a deployment now: its own address while it has a build to
* serve; the branch's alias while it is its branch's latest; the project's own while
* it is the current production one. A failed or stopped one serves nothing. */
function domainsOf(r: Row, branch: string): Domain[] {
if (r.status === "error" || r.status === "canceled") return []
const slug = r.project.name
const latest = r.environment === "preview" || r.current
return [
...(r.current ? (CUSTOM[slug] ?? []) : []).map((host) => ({
host,
kind: "custom" as const,
})),
...(latest
? [
{
host: `${slug}-git-${branch}-adriangalileas-projects.vercel.app`,
kind: "branch" as const,
},
]
: []),
{
host: `${slug}-${r.id.toLowerCase().slice(0, 9)}-adriangalileas-projects.vercel.app`,
kind: "unique" as const,
},
]
}
const CUSTOM: Record<string, readonly string[]> = {
"untitled-garden": [
"untitled.garden",
"www.untitled.garden",
"garden.adriangalilea.com",
"untitled-garden.vercel.app",
"untitled-garden-adriangalileas-projects.vercel.app",
"seeds.untitled.garden",
"map.untitled.garden",
"api.untitled.garden",
"assets.untitled.garden",
"status.untitled.garden",
"beta.untitled.garden",
],
ui: ["ui.adriangalilea.com", "ui-adriangalileas-projects.vercel.app"],
"adriangalilea-com": ["adriangalilea.com", "www.adriangalilea.com"],
tempo: ["tempo.untitled.garden"],
}
/** Each project's live home, captured at a laptop's width: what a deployment's
* preview is a picture of. */
const PREVIEWS: Record<string, string> = {
"untitled-garden": "/deployment/untitled-garden.jpg",
ui: "/deployment/ui.jpg",
"adriangalilea-com": "/deployment/adriangalilea-com.jpg",
tempo: "/deployment/tempo.jpg",
}
interface Row {
id: string
project: Project
message: string
sha: string
author: (typeof AUTHORS)[keyof typeof AUTHORS]
status: DeploymentState
environment: Environment
current?: true
branch?: string
/** How long ago it was created, ms before NOW. */
ago: number
/** How long its build ran, ms. */
took?: number
}
/** A deployment with everything a page of its own shows, from a row of facts. */
function deploymentOf(
r: Row,
): Deployment & Required<Pick<Deployment, "build">> {
const branch = r.branch ?? "main"
const created = NOW - r.ago
const started = r.status === "queued" ? undefined : created + 4_000
const repo =
r.project.name === "untitled-garden" ? "untitled" : r.project.name
const script =
r.status === "error"
? failing(repo, branch, r.sha)
: steps(repo, branch, r.sha)
const ran = r.took ?? 0
const build =
started === undefined
? { lines: [], spans: [] }
: r.status === "canceled"
? buildOf(
r.id,
started,
ran,
script.filter((s) => s.to <= 21_800),
)
: buildOf(r.id, started, ran, script)
const ready = r.status === "ready"
return {
id: r.id,
project: r.project,
commit: { sha: r.sha, message: r.message, author: r.author },
branch,
environment: r.environment,
current: r.current,
status: r.status,
created,
started,
duration: started === undefined ? undefined : ran,
domains: domainsOf(r, branch),
// A picture of the page it serves: none for a build that serves nothing yet.
preview: r.status === "ready" ? PREVIEWS[r.project.name] : undefined,
build,
recommendations: [
{
title: "Turn on Fluid compute",
detail:
"Its functions start cold on every request; Fluid compute keeps one warm and serves requests side by side.",
},
{
title: "Build on Node.js 24",
detail: "Node.js 20 is no longer maintained after April 30, 2026.",
},
],
resources: ready
? [
{ kind: "middleware", name: "middleware", detail: "Edge, 41 kB" },
{
kind: "function",
name: "/api/og",
detail: "iad1, Node.js 22, 2.1 MB",
},
{
kind: "function",
name: "/api/trace",
detail: "iad1, Node.js 22, 0.9 MB",
},
{
kind: "function",
name: "/[item]",
detail: "iad1, Node.js 22, 4.8 MB",
},
{
kind: "static",
name: "/_next/static (1,204 files)",
detail: "38.2 MB",
},
{ kind: "static", name: "/lightbox (11 files)", detail: "6.4 MB" },
]
: [],
checks: ready
? [
{
name: "Lighthouse, mobile",
state: "pending",
detail: "waiting for the first visit",
},
{ name: "Links", state: "passed", detail: "312 checked" },
]
: [],
}
}
const ROWS: Row[] = [
{
id: "Ht2LmQpRa",
project: PROJECTS.ui,
message: "feat(log): a stream of log lines that follows the tail",
sha: "0f6a92e",
author: AUTHORS.adrian,
status: "ready",
environment: "preview",
branch: "log",
ago: 3 * HOUR + 12 * MIN,
took: 129_000,
},
{
id: "FF9zVMDas",
project: PROJECTS.garden,
message: "fix(ui): the lightbox strip's play mark without a grey square",
sha: "a08775a",
author: AUTHORS.adrian,
status: "ready",
environment: "production",
current: true,
ago: 11 * HOUR + 4 * MIN,
took: 91_000,
},
{
id: "D4kWv8nXe",
project: PROJECTS.ui,
message: "test(form-core): wait on state, not on sleeps",
sha: "44911f6",
author: AUTHORS.adrian,
status: "ready",
environment: "production",
current: true,
ago: 11 * HOUR + 31 * MIN,
took: 142_000,
},
{
id: "Rk7pYc2Lf",
project: PROJECTS.garden,
message: "feat(garden): seasons on the map",
sha: "c31e09b",
author: AUTHORS.buzz,
status: "error",
environment: "preview",
branch: "seasons",
ago: 14 * HOUR,
took: 65_000,
},
{
id: "Qm3TfB9wz",
project: PROJECTS.ui,
message: "fix(player): no chapters until the length is known",
sha: "70b485b",
author: AUTHORS.adrian,
status: "ready",
environment: "production",
ago: 16 * HOUR + 20 * MIN,
took: 150_000,
},
{
id: "Jv5sNe1Ku",
project: PROJECTS.ui,
message: "docs(trace): the zoom keys in its header",
sha: "efe90c4",
author: AUTHORS.neil,
status: "queued",
environment: "preview",
branch: "trace-keys",
ago: 40_000,
},
{
id: "Wb8cZr4Ho",
project: PROJECTS.garden,
message: "chore: bump swift-senses (animals follow the light)",
sha: "a076ae2",
author: AUTHORS.adrian,
status: "ready",
environment: "production",
ago: 2 * 24 * HOUR + 3 * HOUR,
took: 42_000,
},
{
id: "Xa9dPq6Mt",
project: PROJECTS.site,
message: "chore(ui): update registry items, keyboard first",
sha: "8cc8664",
author: AUTHORS.adrian,
status: "ready",
environment: "production",
current: true,
ago: 4 * 24 * HOUR + 6 * HOUR,
took: 97_000,
},
{
id: "Ge2vLs7Ny",
project: PROJECTS.tempo,
message: "fix(deps): sharp 0.35.4 (GHSA-rgj7-g3qw-4m6q)",
sha: "7e914be",
author: AUTHORS.adrian,
status: "ready",
environment: "production",
current: true,
ago: 40 * 24 * HOUR,
took: 21_000,
},
{
id: "Pt6hUw3Cx",
project: PROJECTS.tempo,
message: "wip: faces that tick",
sha: "2ca738f",
author: AUTHORS.buzz,
status: "canceled",
environment: "preview",
branch: "faces",
ago: 42 * 24 * HOUR,
took: 18_000,
},
]
const DEPLOYMENTS = ROWS.map(deploymentOf)
/** The project's other pages, a card each at the foot. */
const LINKS: DeploymentLink[] = [
{
title: "Runtime Logs",
description: "View and debug runtime logs & errors",
href: "#runtime-logs",
},
{
title: "Observability",
description: "Monitor app health & performance",
href: "#observability",
},
{
title: "Speed Insights",
description: "Performance metrics from real users",
href: "#speed-insights",
note: "Not Enabled",
},
{
title: "Web Analytics",
description: "Analyze visitors & traffic in real-time",
href: "#web-analytics",
note: "Not Enabled",
},
]
/** The steps a Vercel deployment reports: its build, what it put out, the checks run
* on it, and its domains being pointed at it. */
function VercelSteps({ deployment: d }: { deployment: Deployment }) {
return (
<>
<DeploymentBuild />
<DeploymentSummary />
<DeploymentChecks />
<DeploymentStep
value="domains"
title="Assigning Custom Domains"
state={
d.status === "ready"
? "passed"
: d.status === "error" || d.status === "canceled"
? "skipped"
: "pending"
}
>
{d.domains.length === 0 ? (
<p className="m-0 text-current/55">No domains point here.</p>
) : (
<ul className="m-0 flex list-none flex-col gap-2 p-0">
{d.domains.map((domain) => (
<li
key={domain.host}
className="flex min-w-0 items-center gap-2.5"
>
<span className="truncate">{domain.host}</span>
<span className="ml-auto shrink-0 text-current/55 text-xs">
{domain.kind}
</span>
</li>
))}
</ul>
)}
</DeploymentStep>
</>
)
}
/** The verbs under ⋯ for a deployment. */
const actionsOf = (d: Deployment): MenuEntry[] => [
{
icon: <Link2 />,
label: "Copy URL",
onSelect: () => {
const own = d.domains.find((x) => x.kind === "unique")
if (own) void navigator.clipboard.writeText(`https://${own.host}`)
},
},
{
icon: <FileCode />,
label: "View Source",
onSelect: () =>
window.open(
`https://github.com/adriangalilea/${d.project.name}/commit/${d.commit.sha}`,
"_blank",
"noopener",
),
},
]
// #endregion
// #region page
/** The details page as an address: the deployment its `?id=` names, else the
* current production one. The list's rows link here. */
function DetailsPage() {
const id = useSearchParams().get("id")
return <Details deployment={byId(id)} />
}
const byId = (id: string | null) =>
DEPLOYMENTS.find((d) => d.id === id) ??
(DEPLOYMENTS.find((d) => d.id === "FF9zVMDas") as Deployment)
function Details({ deployment }: { deployment: Deployment }) {
return (
<div className="flex flex-col gap-4">
<Breadcrumb
separator={<span className="text-current/30">/</span>}
crumbs={[
{ label: "Deployments", href: "/deployment/list" },
{
label: (
<span className="inline-flex items-center gap-1 text-current">
{deployment.id}
<Copy value={deployment.id} className="size-6" />
</span>
),
},
]}
/>
<DeploymentDetails
deployment={deployment}
now={NOW}
actions={actionsOf(deployment)}
links={LINKS}
>
<VercelSteps deployment={deployment} />
</DeploymentDetails>
</div>
)
}
// #endregion
// #region live
/** How long the live build waits for a builder, and how much faster than the build
* it plays: 95 s of build in about 16 s. */
const QUEUE_MS = 4_000
const SPEED = 6
const TICK_MS = 100
/** The deployment the live build becomes. */
const LIVE = deploymentOf({
id: "Bn4yHk8Sd",
project: PROJECTS.ui,
message: "feat(deployment): a list of deployments and one in full",
sha: "3b9f1e7",
author: AUTHORS.adrian,
status: "ready",
environment: "production",
current: true,
ago: 0,
took: SCRIPT_MS,
})
/** The live deployment `t` ms after it was created: queued, then building (the lines
* written by then, the spans begun by then, those still running cut at now), then
* ready. */
function liveAt(t: number): Deployment {
if (t >= QUEUE_MS + SCRIPT_MS) return LIVE
// Until it is ready it serves nothing: its own address only, no picture, not
// current, nothing put out or checked yet.
const unready = {
...LIVE,
duration: undefined,
current: undefined,
preview: undefined,
domains: LIVE.domains.filter((x) => x.kind === "unique"),
resources: [],
checks: [],
}
if (t < QUEUE_MS)
return {
...unready,
status: "queued",
started: undefined,
build: { lines: [], spans: [] },
}
const now = LIVE.created + t
return {
...unready,
status: "building",
build: {
lines: LIVE.build.lines.filter((l) => l.at <= now),
spans: LIVE.build.spans
.filter((s) => s.from <= now)
.map((s) =>
s.to > now ? { ...s, to: now, status: "running" as const } : s,
),
},
}
}
/** The build played while it is on screen, stopping when it is done; `replay` starts
* it over. */
function useLiveBuild() {
const box = React.useRef<HTMLDivElement>(null)
const [seen, setSeen] = React.useState(false)
const [t, setT] = React.useState(0)
const [run, setRun] = React.useState(0)
React.useEffect(() => {
const el = box.current
if (!el) return
const watch = new IntersectionObserver(([entry]) =>
setSeen(entry?.isIntersecting ?? false),
)
watch.observe(el)
return () => watch.disconnect()
}, [])
const end = QUEUE_MS + SCRIPT_MS
React.useEffect(() => {
if (!seen || t >= end) return
const tick = window.setTimeout(
() => setT((was) => Math.min(end, was + TICK_MS * SPEED)),
TICK_MS,
)
return () => window.clearTimeout(tick)
}, [seen, t, end])
const replay = () => {
setT(0)
setRun((n) => n + 1)
}
return { box, t, run, done: t >= end, replay }
}
function LiveBuild() {
const { box, t, run, done, replay } = useLiveBuild()
const deployment = React.useMemo(() => liveAt(t), [t])
return (
<div ref={box} className="flex flex-col gap-4">
<div className="flex items-center justify-between gap-3">
<span className="font-mono text-current/55 text-xs tabular-nums">
played at {SPEED}× while on screen
</span>
<Button variant="outline" size="sm" disabled={!done} onClick={replay}>
<RotateCcw />
Replay
</Button>
</div>
<DeploymentDetails
key={run}
deployment={deployment}
now={LIVE.created + t}
actions={[{ icon: <RotateCcw />, label: "Redeploy", onSelect: replay }]}
links={LINKS}
>
<DeploymentBuild defaultRunSummary />
<DeploymentSummary />
<DeploymentChecks />
</DeploymentDetails>
</div>
)
}
// #endregion
// #region failed
const FAILED = DEPLOYMENTS.find((d) => d.status === "error") as Deployment
// #endregion
// #region unseen
/** A worker version uploaded by a CI the host cannot read: what it serves, where,
* which commit, and nothing of its build. */
const UNSEEN: Deployment = {
id: "4f1c9a2e-7d3b-4e8a-9c61-0b5d2e7f8a14",
project: { name: "summary-bot" },
commit: {
sha: "fdc148a",
message: "merge: chapter warm-ups past the update",
author: { name: "ci@example.com" },
},
branch: "main",
environment: "production",
current: true,
status: "ready",
created: NOW - 10 * HOUR,
domains: [{ host: "summary-bot.example.workers.dev", kind: "branch" }],
}
// #endregion
export default function DeploymentDemo() {
return (
<div className="space-y-8">
<Sample
name="list"
glance="large"
title="the deployments"
description="filter by author, environment or status: a dashed chip is a suggestion, solid once set. a row links to its page; narrower, columns go rather than squeeze."
with="deployments"
>
<div className="p-4">
<DeploymentList
deployments={DEPLOYMENTS}
now={NOW}
href={(d) => `/deployment/details?id=${d.id}`}
/>
</div>
</Sample>
<Sample
name="details"
title="one deployment"
description="open Build Logs, then Run Summary: the build's spans beside its log, linked both ways. the warnings chip shows warnings and errors only."
with="deployments page"
>
<div className="p-4">
<React.Suspense fallback={<Details deployment={byId(null)} />}>
<DetailsPage />
</React.Suspense>
</div>
</Sample>
<Sample
name="building"
title="a live build"
description="queued, then building: the log follows its tail, the trace grows span by span and the status pulses amber, then ready. it plays only while on screen and stops when done."
with="deployments live"
>
<div className="p-4">
<LiveBuild />
</div>
</Sample>
<Sample
name="failed"
title="a build that failed"
with="deployments failed"
>
<div className="p-4">
<DeploymentDetails
deployment={FAILED}
now={NOW}
actions={actionsOf(FAILED)}
>
<VercelSteps deployment={FAILED} />
</DeploymentDetails>
</div>
</Sample>
<Sample
name="unseen"
title="a build the host never saw"
description="an upload built somewhere else: no build, no length, no steps, nothing to share. what the host knows, and nothing it does not."
with="unseen"
>
<div className="p-4">
<DeploymentDetails deployment={UNSEEN} now={NOW} />
</div>
</Sample>
<Sample name="glass" title="on glass" with="deployments">
<MaterialProvider material="glass">
<div className="flex flex-col gap-6 rounded-xl bg-[url(/lightbox/peaks.jpg)] bg-cover bg-center p-6">
<DeploymentList
deployments={DEPLOYMENTS.slice(0, 5)}
now={NOW}
filters={false}
/>
<DeploymentDetails
deployment={byId(null)}
now={NOW}
actions={actionsOf(byId(null))}
>
<VercelSteps deployment={byId(null)} />
</DeploymentDetails>
</div>
</MaterialProvider>
</Sample>
</div>
)
}the source, every file an install writes
"use client"
// DEPLOYMENTS, as a host's dashboard draws them (Vercel's is the reference for layout
// and density, never for its marks): a list of them under filters, and one
// of them in full (`DeploymentDetails`, ui/deployment-details). Drawn from the facts in
// lib/deployment-core, asserted where they enter.
//
// <DeploymentList deployments={deployments} href={(d) => `/deployments/${d.id}`} />
//
// A ROW is one deployment on one line, 48 px, its columns at fixed widths so every
// row's start where every other's do: the project (its mark and name), the commit's
// message (cut with an ellipsis, whole in its title), the status (a dot, its word, the
// build's duration), the environment (a pill, filled when it is the current one), the
// commit's hash, the branch, and at the end when it was created and who wrote it. A
// row is a link (`href`) or a button (`onOpen`), or neither; the hand lights it.
//
// NARROWER, COLUMNS GO, never squeezed, read from the list's own width (a container
// query, so a narrow column of a wide page drops them too): the branch first, then the
// hash, the message, the environment, then the build's length; the project, the
// status and the time stay, the project's name taking what is left.
//
// THE FILTERS above it: Add Filter (every choice at once) and a dashed chip for each of
// the author, the environment and the status, showing the commonest value; a chip
// opens its choices, read from the deployments the other filters keep, with how many
// each has (so no choice empties the list), and once set it is solid, with its value
// and a way to clear it. The filter is the
// list's own (`defaultFilter`) or the consumer's (`filter`, `onFilterChange`).
//
// THE SMALL PARTS are exported for a page of its own: `DeploymentStatus` (a status's
// dot, amber and pulsing only while it builds, green ready, red error, quiet queued or
// canceled, in the tokens' tones), `EnvironmentBadge`, `CommitRef`, `BranchRef`,
// `ProjectMark`, `AuthorFace`. Times are relative-time's, said as `TIME_WORDS` from
// `now` (a page's own clock, a replay's); without it, from the reader's clock, each
// label ticking while it is seen. A build's running length ticks every second while
// it builds.
//
// Plain, the page's colours: a box of hairlines on the page. `material="glass"` (or a
// glass provider round it) is a pane of the material's glass. Inside a frame already
// drawn (a panel, a tabs box) it draws no box of its own.
import {
CircleArrowUp,
Eye,
GitBranch,
GitCommitHorizontal,
ListFilter,
X,
} from "lucide-react"
import * as React from "react"
import { cn } from "@/lib/utils"
import {
assertDeployments,
type Deployment,
type DeploymentFilter,
type DeploymentState,
durationText,
type Environment,
elapsed,
type FilterKey,
filterChoices,
filterDeployments,
type Project,
} from "@/registry/base-nova/lib/deployment-core"
import type { RelativeOptions } from "@/registry/base-nova/lib/relative-time-core"
import { Avatar } from "@/registry/base-nova/ui/avatar"
import { Badge } from "@/registry/base-nova/ui/badge"
import { Button } from "@/registry/base-nova/ui/button"
import {
type Material,
MaterialProvider,
type Scheme,
useMaterial,
useSurfaceScheme,
} from "@/registry/base-nova/ui/material"
import { schemeOf } from "@/registry/base-nova/ui/material-glass"
import {
DropdownMenu,
DropdownMenuContent,
DropdownMenuLabel,
DropdownMenuRadioGroup,
DropdownMenuRadioItem,
DropdownMenuSeparator,
DropdownMenuTrigger,
} from "@/registry/base-nova/ui/menu"
import { Panel, useInFrame } from "@/registry/base-nova/ui/panel"
import { RelativeTime } from "@/registry/base-nova/ui/relative-time"
import { Status, type StatusTone } from "@/registry/base-nova/ui/status"
// ── words ────────────────────────────────────────────────────────────────────────
export const STATE_WORDS: Record<DeploymentState, string> = {
queued: "Queued",
building: "Building",
ready: "Ready",
error: "Error",
canceled: "Canceled",
}
export const ENVIRONMENT_WORDS: Record<Environment, string> = {
production: "Production",
preview: "Preview",
}
const FILTER_WORDS: Record<FilterKey, string> = {
author: "Author",
environment: "Environment",
status: "Status",
}
/** How the dashboard says a time (relative-time): "just now" for the first minute,
* then minutes, hours, days, and from the third day its date. */
export const TIME_WORDS = {
precision: "minute",
dateAfter: 3,
} as const satisfies RelativeOptions
/** Metadata's voice: mono, tabular, a step back. */
const META = "font-mono text-[13px] tabular-nums text-current/55"
// ── the clock ────────────────────────────────────────────────────────────────────
/** The instant a build's running length is measured to: `given` when there is one (a
* page's own clock, a replay's), else the reader's, read after mount (the server's
* would disagree with the reader's and the two renders with each other), and again
* every second while `live` (something is building). Null until then. */
export function useNow(
given: number | undefined,
live: boolean,
): number | null {
const [own, setOwn] = React.useState<number | null>(null)
React.useEffect(() => {
if (given !== undefined) return
setOwn(Date.now())
if (!live) return
const tick = window.setInterval(() => setOwn(Date.now()), 1000)
return () => window.clearInterval(tick)
}, [given, live])
return given ?? own
}
// ── the small parts ──────────────────────────────────────────────────────────────
const STATE_TONE: Record<DeploymentState, StatusTone> = {
queued: "neutral",
building: "warn",
ready: "ok",
error: "bad",
canceled: "neutral",
}
/** How a deployment stands: a status (its dot in its tone, its word) and the build's
* length (or its running length while it builds). */
export function DeploymentStatus({
status,
duration,
className,
}: {
status: DeploymentState
/** ms; null or absent, none shown. */
duration?: number | null
className?: string
}) {
return (
<Status
data-slot="deployment-status"
data-status={status}
tone={STATE_TONE[status]}
// The one thing that moves, and only while it builds.
pulse={status === "building"}
className={cn("font-medium text-current/90", className)}
>
{STATE_WORDS[status]}
{duration != null && (
<span
data-slot="deployment-duration"
className={cn(META, "font-normal")}
>
{durationText(duration)}
</span>
)}
</Status>
)
}
/** Where it went: production (an arrow up) or a preview, filled in the info tone when
* it is the deployment production serves now. */
export function EnvironmentBadge({
environment,
current = false,
className,
}: {
environment: Environment
current?: boolean
className?: string
}) {
const Icon = environment === "production" ? CircleArrowUp : Eye
return (
<Badge
data-slot="deployment-environment"
data-current={current || undefined}
variant={current ? "info" : "outline"}
className={cn(
"h-6 gap-1 px-2 font-sans text-[13px] normal-case [&_svg]:size-3.5",
!current && "text-current/90",
className,
)}
>
<Icon aria-hidden />
{ENVIRONMENT_WORDS[environment]}
</Badge>
)
}
/** A commit by its short hash, mono, after git's commit mark. */
export function CommitRef({
sha,
className,
}: {
sha: string
className?: string
}) {
return (
<span
data-slot="deployment-commit"
className={cn("inline-flex min-w-0 items-center gap-2", className)}
>
<GitCommitHorizontal
aria-hidden
className="size-4 shrink-0 text-current/55"
/>
<span className="truncate font-mono text-[13px] text-current/90">
{sha.slice(0, 7)}
</span>
</span>
)
}
/** A branch by its name, mono, after git's branch mark. */
export function BranchRef({
branch,
className,
}: {
branch: string
className?: string
}) {
return (
<span
data-slot="deployment-branch"
className={cn("inline-flex min-w-0 items-center gap-2", className)}
>
<GitBranch aria-hidden className="size-4 shrink-0 text-current/55" />
<span className="truncate font-mono text-[13px] text-current/90">
{branch}
</span>
</span>
)
}
/** A project's picture at 16 px, or its initial in a quiet square: never a host's
* logo, which says whose dashboard it is, not which project. */
export function ProjectMark({
project,
className,
}: {
project: Project
className?: string
}) {
if (project.icon)
return (
// biome-ignore lint/performance/noImgElement: an item cannot assume next/image
<img
data-slot="deployment-project-mark"
src={project.icon}
alt=""
width={16}
height={16}
className={cn("size-4 shrink-0 object-contain", className)}
/>
)
return (
<span
aria-hidden
data-slot="deployment-project-mark"
className={cn(
"grid size-4 shrink-0 place-items-center rounded-[4px] bg-current/12 font-medium font-sans text-[10px] text-current/80 uppercase leading-none",
className,
)}
>
{project.name.slice(0, 1)}
</span>
)
}
/** Who wrote the commit: their face at 20 px, or their initial in a disc. */
export function AuthorFace({
author,
className,
}: {
author: Deployment["commit"]["author"]
className?: string
}) {
if (author.avatar)
return (
<Avatar
src={author.avatar}
alt={author.name}
size="sm"
className={cn("size-5", className)}
/>
)
return (
<span
role="img"
aria-label={author.name}
data-slot="deployment-author"
className={cn(
"grid size-5 shrink-0 place-items-center rounded-full bg-current/15 font-medium text-[10px] uppercase",
className,
)}
>
{author.name.slice(0, 1)}
</span>
)
}
// ── the list ─────────────────────────────────────────────────────────────────────
/** The columns' widths, px: Vercel's at 1190 px of list. The branch takes what is
* left, the time and the face sit at the end. */
const COLUMN = {
project: "w-[194px]",
message: "w-[271px]",
status: "w-[209px]",
environment: "w-[131px]",
commit: "w-[141px]",
} as const
/** The list's widths where a column goes, its own width (a container query): the
* branch below 1140 px, the hash below 1070, the message below 930, the environment
* below 660; below 530 the project takes what the status and the time leave. Each
* is the sum of the columns that stay, so nothing is squeezed before it goes. */
const DROP = {
branch: "@max-[1140px]/deployments:hidden",
commit: "@max-[1070px]/deployments:hidden",
message: "@max-[930px]/deployments:hidden",
environment: "@max-[660px]/deployments:hidden",
narrow:
"@max-[530px]/deployments:w-auto @max-[530px]/deployments:min-w-0 @max-[530px]/deployments:flex-1",
} as const
/** A row is 48 px with the hairline under it (Vercel's pitch), so 47 of its own. */
const ROW =
"flex h-[47px] w-full min-w-0 items-center px-4 text-left text-sm outline-none focus-visible:-outline-offset-2"
const ROW_FACE: Record<Material, string> = {
plain: "hover:bg-foreground/[0.035] focus-visible:bg-foreground/[0.035]",
glass: "hover:bg-current/8 focus-visible:bg-current/8",
}
export type DeploymentListProps = Omit<
React.ComponentProps<"div">,
"children"
> & {
deployments: readonly Deployment[]
/** The instant times are said from. Default the reader's clock. */
now?: number
/** Each row a link to its deployment. */
href?: (deployment: Deployment) => string
/** Each row a button that opens its deployment. */
onOpen?: (deployment: Deployment) => void
/** The filters above the rows. Default shown. */
filters?: boolean
/** The filter (controlled), with `onFilterChange`. */
filter?: DeploymentFilter
defaultFilter?: DeploymentFilter
onFilterChange?: (filter: DeploymentFilter) => void
/** The rows' name for assistive tech. Default "deployments". */
label?: string
/** Its own box. Default drawn, except inside a frame already drawn (panel's
* `InFrame`: a panel, a tabs box). */
frame?: boolean
material?: Material
/** The colour scheme it stands in (material): default the nearest provider's. */
scheme?: Scheme
}
export function DeploymentList({
deployments,
now,
href,
onOpen,
filters = true,
filter,
defaultFilter = {},
onFilterChange,
label = "deployments",
frame,
material,
scheme,
className,
ref,
...props
}: DeploymentListProps) {
if (href && onOpen)
throw new Error(
"DeploymentList: a row is a link (href) or a button (onOpen), not both",
)
assertDeployments(deployments)
const m = useMaterial(material)
const inFrame = useInFrame()
const framed = frame ?? !inFrame
const [s, here] = useSurfaceScheme<HTMLDivElement>(scheme, ref)
const [own, setOwn] = React.useState(defaultFilter)
const f = filter ?? own
const setFilter = (next: DeploymentFilter) => {
if (filter === undefined) setOwn(next)
onFilterChange?.(next)
}
const shown = React.useMemo(
() => filterDeployments(deployments, f),
[deployments, f],
)
const clock = useNow(
now,
deployments.some((d) => d.status === "building"),
)
const rows = (
<ul
aria-label={label}
data-slot="deployment-rows"
className="m-0 list-none p-0"
>
{shown.map((d) => (
<li
key={d.id}
data-slot="deployment-row"
data-id={d.id}
data-status={d.status}
className="border-current/10 border-b last:border-b-0"
>
<Row
deployment={d}
now={now}
clock={clock}
href={href}
onOpen={onOpen}
material={m}
/>
</li>
))}
{shown.length === 0 && (
<li
data-slot="deployment-empty"
className="flex h-24 flex-col items-center justify-center gap-2 text-current/55 text-sm"
>
No deployments match these filters.
<Button variant="ghost" size="sm" onClick={() => setFilter({})}>
Clear filters
</Button>
</li>
)}
</ul>
)
return (
<div
ref={here}
data-slot="deployment-list"
data-material={m}
className={cn(
"@container/deployments flex min-w-0 flex-col gap-4",
schemeOf(s),
className,
)}
{...props}
>
<MaterialProvider material={m} scheme={s}>
{filters && (
<Filters deployments={deployments} filter={f} onChange={setFilter} />
)}
{framed ? (
<Panel
className={cn(
"gap-0 overflow-clip p-0",
m === "plain" && "shadow-none",
)}
>
{rows}
</Panel>
) : (
rows
)}
</MaterialProvider>
</div>
)
}
const Row = React.memo(function Row({
deployment: d,
now,
clock,
href,
onOpen,
material,
}: {
deployment: Deployment
/** The list's given instant, when it has one: its times are said from it. */
now: number | undefined
/** What a build's running length is measured to. */
clock: number | null
href: ((d: Deployment) => string) | undefined
onOpen: ((d: Deployment) => void) | undefined
material: Material
}) {
const cells = (
<>
<span
data-slot="deployment-project"
className={cn(
"flex shrink-0 items-center gap-2.5 pr-4",
COLUMN.project,
DROP.narrow,
)}
>
<ProjectMark project={d.project} />
<span className="truncate font-medium text-current/95">
{d.project.name}
</span>
</span>
<span
data-slot="deployment-message"
title={d.commit.message}
className={cn(
"shrink-0 truncate pr-4 text-current/90",
COLUMN.message,
DROP.message,
)}
>
{d.commit.message}
</span>
<span
className={cn(
"flex shrink-0 pr-4",
COLUMN.status,
// Narrow, the build's length goes too, and the status is as wide as its
// widest word ("Canceled"), so it starts where every other row's does.
"@max-[530px]/deployments:w-28 @max-[530px]/deployments:[&_[data-slot=deployment-duration]]:hidden",
)}
>
<DeploymentStatus status={d.status} duration={elapsed(d, clock)} />
</span>
<span
className={cn(
"flex shrink-0 pr-4",
COLUMN.environment,
DROP.environment,
)}
>
<EnvironmentBadge environment={d.environment} current={d.current} />
</span>
<CommitRef
sha={d.commit.sha}
className={cn("shrink-0 pr-4", COLUMN.commit, DROP.commit)}
/>
<BranchRef
branch={d.branch}
className={cn("min-w-0 flex-1 pr-4", DROP.branch)}
/>
{/* As wide as "just now" and the face, the time to its end, so a column left of
it never moves with its words; a date with its year runs left into the
column's room. */}
<span
data-slot="deployment-when"
className="ml-auto flex w-24 shrink-0 items-center justify-end gap-2.5"
>
<RelativeTime
data-slot="deployment-ago"
at={d.created}
now={now}
{...TIME_WORDS}
className={META}
/>
<AuthorFace author={d.commit.author} />
</span>
</>
)
const look = cn(ROW, (href || onOpen) && ROW_FACE[material])
if (href)
return (
<a href={href(d)} className={cn(look, "text-current")}>
{cells}
</a>
)
if (onOpen)
return (
<button
type="button"
onClick={() => onOpen(d)}
className={cn(look, "cursor-pointer")}
>
{cells}
</button>
)
return <div className={look}>{cells}</div>
})
// ── the filters ──────────────────────────────────────────────────────────────────
const KEYS: readonly FilterKey[] = ["author", "environment", "status"]
/** A filter's value as the list says it. */
function valueWords(key: FilterKey, value: string): string {
if (key === "environment") return ENVIRONMENT_WORDS[value as Environment]
if (key === "status") return STATE_WORDS[value as DeploymentState]
return value
}
function Filters({
deployments,
filter,
onChange,
}: {
deployments: readonly Deployment[]
filter: DeploymentFilter
onChange: (f: DeploymentFilter) => void
}) {
// Each filter's choices are counted among what the OTHER filters keep, so a choice
// never empties the list (a person's only deployment was queued: under Status
// Ready, they are not offered).
const choices = React.useMemo(() => {
const without = (key: FilterKey) => {
const rest: DeploymentFilter = { ...filter }
delete rest[key]
return filterChoices(filterDeployments(deployments, rest))
}
return {
author: without("author").author,
environment: without("environment").environment,
status: without("status").status,
}
}, [deployments, filter])
const set = (key: FilterKey, value: string | undefined) => {
const next: DeploymentFilter = { ...filter }
if (value === undefined) delete next[key]
else Object.assign(next, { [key]: value })
onChange(next)
}
return (
<div
data-slot="deployment-filters"
className="flex flex-wrap items-center gap-2"
>
<DropdownMenu>
<DropdownMenuTrigger
render={
<Button variant="outline" corners="pill" className="px-3.5">
<ListFilter aria-hidden />
Add Filter
</Button>
}
/>
<DropdownMenuContent align="start" className="min-w-56">
{KEYS.map((key, i) => (
<React.Fragment key={key}>
{i > 0 && <DropdownMenuSeparator />}
<Choices
name={key}
choices={choices[key]}
value={filter[key]}
onValueChange={(v) => set(key, v)}
/>
</React.Fragment>
))}
</DropdownMenuContent>
</DropdownMenu>
{KEYS.map((key) => (
<Chip
key={key}
name={key}
choices={choices[key]}
value={filter[key]}
onValueChange={(v) => set(key, v)}
/>
))}
</div>
)
}
/** One filter's choices as radio rows, each with how many deployments it keeps. */
function Choices({
name,
choices,
value,
onValueChange,
}: {
name: FilterKey
choices: readonly { value: string; count: number }[]
value: string | undefined
onValueChange: (value: string) => void
}) {
return (
<>
<DropdownMenuLabel>{FILTER_WORDS[name]}</DropdownMenuLabel>
<DropdownMenuRadioGroup
value={value ?? null}
onValueChange={(v) => onValueChange(v as string)}
>
{choices.map((c) => (
<DropdownMenuRadioItem key={c.value} value={c.value}>
<span className="flex flex-1 items-center justify-between gap-4">
{valueWords(name, c.value)}
<span className="font-mono text-[11px] text-current/45 tabular-nums">
{c.count}
</span>
</span>
</DropdownMenuRadioItem>
))}
</DropdownMenuRadioGroup>
</>
)
}
/** A filter as a chip. Unset, it is a suggestion, dashed, naming its value: a press
* applies exactly that value, as the chip says. Set, it is solid: a press opens its
* choices to change it, and its × clears it. */
function Chip({
name,
choices,
value,
onValueChange,
}: {
name: FilterKey
choices: readonly { value: string; count: number }[]
value: string | undefined
onValueChange: (value: string | undefined) => void
}) {
const set = value !== undefined
// The suggestion: the commonest value, or for the status what went wrong, when
// anything did (what a person filters a list of builds for).
const shown =
value ??
(name === "status" && choices.some((c) => c.value === "error")
? "error"
: choices[0]?.value)
if (shown === undefined) return null
if (!set)
return (
<Button
variant="ghost"
corners="pill"
data-slot="deployment-filter"
aria-label={`filter by ${FILTER_WORDS[name].toLowerCase()}: ${valueWords(name, shown)}`}
onClick={() => onValueChange(shown)}
className="h-8 gap-1.5 border border-current/25 border-dashed px-3 font-normal text-current/50 text-sm"
>
<span>{FILTER_WORDS[name]}</span>
<span>{valueWords(name, shown)}</span>
</Button>
)
return (
<span
data-slot="deployment-filter"
data-set=""
className="inline-flex h-8 items-center rounded-full border border-current/20 bg-current/[0.04]"
>
<DropdownMenu>
<DropdownMenuTrigger
render={
<Button
variant="ghost"
corners="pill"
className="h-full gap-1.5 px-3 pr-1.5 font-normal text-sm"
>
<span className="text-current/55">{FILTER_WORDS[name]}</span>
<span className="font-medium">{valueWords(name, shown)}</span>
</Button>
}
/>
<DropdownMenuContent align="start" className="min-w-48">
<Choices
name={name}
choices={choices}
value={value}
onValueChange={onValueChange}
/>
</DropdownMenuContent>
</DropdownMenu>
<Button
variant="ghost"
size="icon-sm"
corners="pill"
aria-label={`clear the ${FILTER_WORDS[name].toLowerCase()} filter`}
onClick={() => onValueChange(undefined)}
className="mr-0.5 size-6 text-current/55"
>
<X />
</Button>
</span>
)
}"use client"
// ONE DEPLOYMENT IN FULL, the body of a host's deployment page (the rows and parts are
// ui/deployment's). It draws what the deployment carries and nothing else: a part the
// host does not know is absent, never an empty box, a made-up check or a button with
// nowhere to go (lib/deployment-core, "known").
//
// <DeploymentDetails deployment={d} links={[…]} actions={[…]}>
// <DeploymentBuild />
// <DeploymentSummary />
// <DeploymentChecks />
// <DeploymentStep value="domains" title="Assigning Custom Domains" state="passed">…</DeploymentStep>
// </DeploymentDetails>
//
// Steps may be wrapped in the consumer's own components; a deployment carrying a build
// must show it (DeploymentBuild among them), or the page throws.
//
// THE FIRST BOX: its head (Share for a deployment with an address of its own, Logs for
// the build shown below, Visit with every domain serving it under its chevron, ⋯
// with the consumer's verbs), a picture of the page beside the facts when the host
// took one, the facts (who created it and when, its status, how long the build took
// and when it ended for a build the host saw, its environment and whether it is
// current), the domains serving it (three, the rest behind +N), its source (the
// branch, the commit), and the settings the platform recommends when it recommends.
//
// THE STEPS are the children, each a section that opens in place (accordion), its
// state at its end: a check when it passed, a clock while it waits, a spinner while it
// runs, a cross when it failed, a dash when it was skipped. The consumer composes the
// ones it can feed, and each built-in step asserts its part is there:
//
// DeploymentBuild the build's log (ui/log), its own height, drawing no box of its
// own. Its warnings and errors are counted from its lines; a count
// is a toggle that shows that level and above. Run Summary lays
// the build's spans beside it as a trace (ui/trace), linked both
// ways as lib/telemetry's demo links them. The length the build
// took, or has taken.
// DeploymentSummary what the build put out (functions, static assets, the
// middleware), narrowed by kind from Resources.
// DeploymentChecks what ran on it once built.
// DeploymentStep any other step the host reports, its state given (the domains
// being pointed at it, a migration, a promotion).
//
// THE FOOT: the consumer's links to the project's other pages (`links`), a card each.
//
// Plain, boxes of the page's card on the page; glass, panes of the material's glass
// (panel). Every control is the registry's own: Button, Badge, Popover, the menu's
// dropdown, Copy, Accordion, Log, Trace.
import {
ChartNoAxesGantt,
ChevronDown,
CircleArrowUp,
CircleCheck,
CircleMinus,
CircleX,
Clock,
Ellipsis,
Eye,
FileCode,
GitBranch,
GitCommitHorizontal,
Globe,
ListFilter,
Logs,
Route,
Share,
SquareFunction,
TriangleAlert,
} from "lucide-react"
import * as React from "react"
import { cn } from "@/lib/utils"
import {
assertDeployment,
buildCounts,
buildState,
checksState,
type Deployment,
type Domain,
durationText,
elapsed,
outputState,
RESOURCE_KINDS,
type ResourceKind,
type StepState,
} from "@/registry/base-nova/lib/deployment-core"
import type { LogLevel } from "@/registry/base-nova/lib/telemetry"
import {
Accordion,
AccordionContent,
AccordionItem,
AccordionTrigger,
} from "@/registry/base-nova/ui/accordion"
import { Badge } from "@/registry/base-nova/ui/badge"
import { Button, ButtonGroup } from "@/registry/base-nova/ui/button"
import { Copy } from "@/registry/base-nova/ui/copy"
import {
AuthorFace,
DeploymentStatus,
ENVIRONMENT_WORDS,
TIME_WORDS,
useNow,
} from "@/registry/base-nova/ui/deployment"
import { Log } from "@/registry/base-nova/ui/log"
import {
type Material,
MaterialProvider,
type Scheme,
TONE_WORDS,
useMaterial,
useSurfaceScheme,
} from "@/registry/base-nova/ui/material"
import { schemeOf } from "@/registry/base-nova/ui/material-glass"
import {
DropdownMenu,
DropdownMenuContent,
DropdownMenuItem,
DropdownMenuLabel,
DropdownMenuLinkItem,
DropdownMenuRadioGroup,
DropdownMenuRadioItem,
DropdownMenuSeparator,
DropdownMenuTrigger,
type MenuEntry,
} from "@/registry/base-nova/ui/menu"
import { Panel } from "@/registry/base-nova/ui/panel"
import {
Popover,
PopoverContent,
PopoverDescription,
PopoverTitle,
PopoverTrigger,
} from "@/registry/base-nova/ui/popover"
import { RelativeTime } from "@/registry/base-nova/ui/relative-time"
import { Spinner } from "@/registry/base-nova/ui/spinner"
import { Trace } from "@/registry/base-nova/ui/trace"
/** The settings' section; every other section is a step, named by its `value`. */
const SETTINGS = "settings"
/** The build step's section. */
const BUILD = "build"
/** A page of the project's beside this one, a card at the foot. */
export interface DeploymentLink {
title: string
description: string
href: string
/** A word at its corner ("Not Enabled"). */
note?: string
}
export type DeploymentDetailsProps = {
deployment: Deployment
/** The instant times are said from. Default the reader's clock. */
now?: number
/** The sections open at first, by value (`"settings"`, a step's). Default the
* build's while it waits, builds, or when it failed; none once ready or canceled. */
defaultOpen?: readonly string[]
/** The verbs under ⋯ (the menu's entries: redeploy, promote, roll back). None, no ⋯. */
actions?: readonly MenuEntry[]
/** The cards at the foot. */
links?: readonly DeploymentLink[]
/** The steps, each a direct child: DeploymentBuild, DeploymentSummary,
* DeploymentChecks, DeploymentStep. None, no box of steps. */
children?: React.ReactNode
material?: Material
/** The colour scheme it stands in (material): default the nearest provider's. */
scheme?: Scheme
className?: string
}
/** What the steps read from the page they stand on. */
interface DetailsState {
deployment: Deployment
now: number | undefined
/** The build's length, or its running length while it builds. */
took: number | null
/** Opens a section (the build's, when a count or Run Summary is pressed). */
opening: (value: string) => void
/** The build step's place, where Logs scrolls to. */
build: React.RefObject<HTMLDivElement | null>
}
const Details = React.createContext<DetailsState | null>(null)
function useDetails(part: string): DetailsState {
const state = React.useContext(Details)
if (!state) throw new Error(`${part}: a step of DeploymentDetails, inside it`)
return state
}
/** A box: the page's card in plain, a pane of glass in glass (panel). */
const BOX = "gap-0 overflow-clip p-0"
/** The facts' names. */
const NAME = "text-sm text-current/55"
const META = "font-mono text-[13px] tabular-nums text-current/55"
const ROW_TITLE =
"h-14 px-4 py-0 font-normal text-[15px] hover:no-underline [&>svg]:hover:text-current"
export function DeploymentDetails({
deployment: d,
now,
defaultOpen,
actions,
links,
children,
material,
scheme,
className,
}: DeploymentDetailsProps) {
assertDeployment(d)
const m = useMaterial(material)
const [s, here] = useSurfaceScheme<HTMLDivElement>(scheme)
const clock = useNow(now, d.status === "building")
const took = elapsed(d, clock)
const steps = React.Children.toArray(children)
const buildShown = d.build !== undefined
const [open, setOpen] = React.useState<readonly string[]>(
() =>
defaultOpen ??
(buildShown && d.status !== "ready" && d.status !== "canceled"
? [BUILD]
: []),
)
const opening = React.useCallback(
(value: string) =>
setOpen((was) => (was.includes(value) ? was : [...was, value])),
[],
)
const build = React.useRef<HTMLDivElement>(null)
// A build the host saw is shown: Logs goes to it, and a page holding it back is a
// confused program.
React.useEffect(() => {
if (buildShown && !build.current)
throw new Error(
`DeploymentDetails: deployment "${d.id}" has a build and no DeploymentBuild among its steps`,
)
}, [buildShown, d.id])
const state = React.useMemo(
() => ({ deployment: d, now, took, opening, build }),
[d, now, took, opening],
)
const own = d.domains.find((x) => x.kind === "unique")
const header = (
<header
data-slot="deployment-details-head"
className="flex min-h-14 flex-wrap items-center justify-between gap-x-4 gap-y-2 border-current/10 border-b px-4 py-3"
>
<h2 className="m-0 font-medium text-[15px]">Deployment Details</h2>
<div className="flex items-center gap-2">
{own && <SharePopover host={own.host} />}
{buildShown && (
<Button
variant="outline"
onClick={() => {
opening(BUILD)
requestAnimationFrame(() =>
build.current?.scrollIntoView({ block: "nearest" }),
)
}}
>
<Logs aria-hidden />
Logs
</Button>
)}
{d.domains.length > 0 && <Visit deployment={d} />}
{actions && actions.length > 0 && (
<DropdownMenu>
<DropdownMenuTrigger
render={
<Button variant="ghost" size="icon" aria-label="more">
<Ellipsis />
</Button>
}
/>
<DropdownMenuContent className="min-w-52">
{actions.map((entry, i) =>
entry === "separator" ? (
// biome-ignore lint/suspicious/noArrayIndexKey: the entries are the consumer's list, its place is its identity
<DropdownMenuSeparator key={i} />
) : (
<DropdownMenuItem
// biome-ignore lint/suspicious/noArrayIndexKey: the entries are the consumer's list, its place is its identity
key={i}
disabled={entry.disabled}
destructive={entry.destructive}
onClick={entry.onSelect}
>
{entry.icon}
{entry.label}
</DropdownMenuItem>
),
)}
</DropdownMenuContent>
</DropdownMenu>
)}
</div>
</header>
)
const recommendations = d.recommendations
return (
<div
ref={here}
data-slot="deployment-details"
data-material={m}
data-status={d.status}
className={cn(
"@container/details flex min-w-0 flex-col gap-4 text-sm",
schemeOf(s),
className,
)}
>
<MaterialProvider material={m} scheme={s}>
<Details.Provider value={state}>
<Panel className={BOX}>
{header}
<div
className={cn(
"grid gap-6 p-4",
d.preview &&
"@3xl/details:grid-cols-[minmax(0,25rem)_minmax(0,1fr)]",
)}
>
{d.preview && <Preview deployment={d} src={d.preview} />}
<Facts deployment={d} now={now} took={took} />
</div>
{recommendations && (
<Accordion
multiple
value={open.filter((x) => x === SETTINGS)}
onValueChange={(v) =>
setOpen((was) => [
...was.filter((x) => x !== SETTINGS),
...(v as string[]),
])
}
className="border-current/10 border-t"
>
<AccordionItem value={SETTINGS} className="border-current/10">
<AccordionTrigger
chevron="start"
className={cn(ROW_TITLE, "h-12")}
>
Deployment Settings
{recommendations.length > 0 && (
<Badge
variant="info"
className="h-6 px-2.5 font-sans text-[13px] normal-case"
>
{recommendations.length}{" "}
{recommendations.length === 1
? "Recommendation"
: "Recommendations"}
</Badge>
)}
</AccordionTrigger>
<AccordionContent className="px-4 pb-4 pl-11">
{recommendations.length === 0 ? (
<p className="m-0 text-current/55">Nothing to change.</p>
) : (
<ul className="m-0 flex list-none flex-col gap-3 p-0">
{recommendations.map((r) => (
<li key={r.title} className="flex flex-col gap-0.5">
<span className="font-medium text-current/95">
{r.title}
</span>
<span className="text-current/60">{r.detail}</span>
</li>
))}
</ul>
)}
</AccordionContent>
</AccordionItem>
</Accordion>
)}
</Panel>
{steps.length > 0 && (
<Panel className={BOX}>
<Accordion
multiple
value={open.filter((x) => x !== SETTINGS)}
onValueChange={(v) =>
setOpen((was) => [
...was.filter((x) => x === SETTINGS),
...(v as string[]),
])
}
>
{steps}
</Accordion>
</Panel>
)}
{links && links.length > 0 && (
<nav
aria-label="the project's pages"
data-slot="deployment-details-links"
className="grid gap-3 @xl/details:grid-cols-2 @5xl/details:grid-cols-4"
>
{links.map((link) => (
// The note beside the title, the description under both at the
// card's whole width (a panel's action would take it from the line).
<Panel
key={link.href}
render={<a href={link.href} />}
data-slot="deployment-details-link"
className={cn(
"gap-1 px-4 py-3.5 transition-colors",
m === "plain"
? "shadow-none hover:bg-foreground/[0.03]"
: "hover:[--glass-rim:1.5]!",
)}
>
<span className="flex min-h-6 items-center justify-between gap-3">
<span className="font-medium text-[15px]">
{link.title}
</span>
{link.note && (
<Badge
variant="secondary"
className="font-sans text-xs normal-case"
>
{link.note}
</Badge>
)}
</span>
<span className="text-current/60">{link.description}</span>
</Panel>
))}
</nav>
)}
</Details.Provider>
</MaterialProvider>
</div>
)
}
// ── the first box ────────────────────────────────────────────────────────────────
/** The picture the host took of the deployed page. */
function Preview({
deployment: d,
src,
}: {
deployment: Deployment
src: string
}) {
return (
<div
data-slot="deployment-preview"
className="relative aspect-[16/10] w-full overflow-hidden rounded-md bg-current/5 ring-1 ring-current/10"
>
{/* biome-ignore lint/performance/noImgElement: an item cannot assume next/image */}
<img
src={src}
alt={`${d.project.name}, as deployed`}
className="absolute inset-0 size-full object-cover object-top"
/>
</div>
)
}
/** One fact: its name over its value. */
function Fact({
name,
children,
className,
}: {
name: string
children: React.ReactNode
className?: string
}) {
return (
<div className={cn("flex min-w-0 flex-col gap-1.5", className)}>
<dt className={NAME}>{name}</dt>
<dd className="m-0 flex min-w-0 items-center gap-2 whitespace-nowrap leading-6">
{children}
</dd>
</div>
)
}
const DOMAIN_MARK: Record<Domain["kind"], typeof Globe> = {
custom: Globe,
branch: GitBranch,
unique: GitCommitHorizontal,
}
/** The domains shown at first: the project's own, the branch's, its own. */
const firstDomains = (domains: readonly Domain[]): Domain[] => {
const shown: Domain[] = []
for (const kind of ["custom", "branch", "unique"] as const) {
const one = domains.find((x) => x.kind === kind)
if (one) shown.push(one)
}
return shown
}
function DomainLink({ domain }: { domain: Domain }) {
const Mark = DOMAIN_MARK[domain.kind]
return (
<span className="flex min-w-0 items-center gap-2.5">
<Mark aria-hidden className="size-4 shrink-0 text-current/55" />
<a
href={`https://${domain.host}`}
target="_blank"
rel="noreferrer"
className="truncate text-current/95 hover:underline"
>
{domain.host}
</a>
</span>
)
}
function Facts({
deployment: d,
now,
took,
}: {
deployment: Deployment
/** The page's given instant, when it has one: its times are said from it. */
now: number | undefined
took: number | null
}) {
const shown = firstDomains(d.domains)
const rest = d.domains.filter((x) => !shown.includes(x))
const EnvMark = d.environment === "production" ? CircleArrowUp : Eye
return (
// Four facts a row from 44 rem of their own width (each about 11 rem, what
// "adriangalilea 11h ago" takes), two below it.
<dl className="@container/facts m-0 flex min-w-0 flex-col gap-5">
<div className="grid grid-cols-2 gap-x-4 gap-y-5 @[44rem]/facts:grid-cols-4">
<Fact name="Created">
<AuthorFace author={d.commit.author} />
<span className="truncate">{d.commit.author.name}</span>
<RelativeTime
data-slot="deployment-ago"
at={d.created}
now={now}
{...TIME_WORDS}
className={cn(META, "shrink-0")}
/>
</Fact>
<Fact name="Status">
<DeploymentStatus status={d.status} />
</Fact>
{/* A build the host never saw has no length to say. */}
{d.build && (
<Fact name="Duration">
<Clock aria-hidden className="size-4 shrink-0 text-current/55" />
{took === null ? (
<span className={META}>not started</span>
) : (
<>
<span className="font-mono text-[13px] text-current/95 tabular-nums">
{durationText(took)}
</span>
{d.duration !== undefined && d.started !== undefined && (
<RelativeTime
data-slot="deployment-ago"
at={d.started + d.duration}
now={now}
{...TIME_WORDS}
className={META}
/>
)}
</>
)}
</Fact>
)}
<Fact name="Environment">
<EnvMark aria-hidden className="size-4 shrink-0 text-current/55" />
<span>{ENVIRONMENT_WORDS[d.environment]}</span>
{d.current && (
<Badge
variant="info"
className="h-5 px-2 font-sans text-xs normal-case"
>
Current
</Badge>
)}
</Fact>
</div>
{d.domains.length > 0 && (
<div className="flex min-w-0 flex-col gap-1.5">
<dt className={NAME}>Domains</dt>
<dd className="m-0 grid min-w-0 grid-cols-[minmax(0,1fr)_auto] items-start gap-x-3">
<ul className="m-0 flex min-w-0 list-none flex-col gap-1 p-0 leading-6">
{shown.map((domain) => (
<li key={domain.host} className="min-w-0">
<DomainLink domain={domain} />
</li>
))}
</ul>
{rest.length > 0 && (
<Popover>
<PopoverTrigger
render={
<Button
variant="secondary"
size="sm"
corners="pill"
aria-label={`${rest.length} more domains`}
className="h-6 px-2 font-mono tabular-nums"
>
+{rest.length}
</Button>
}
/>
<PopoverContent align="end" className="w-80 gap-2">
<PopoverTitle>All domains</PopoverTitle>
<ul className="m-0 flex list-none flex-col gap-1 p-0 leading-6">
{d.domains.map((domain) => (
<li key={domain.host} className="min-w-0">
<DomainLink domain={domain} />
</li>
))}
</ul>
</PopoverContent>
</Popover>
)}
</dd>
</div>
)}
<div className="flex min-w-0 flex-col gap-1.5">
<dt className={NAME}>Source</dt>
<dd className="m-0 flex min-w-0 flex-col gap-1 leading-6">
<span className="flex min-w-0 items-center gap-2.5">
<GitBranch
aria-hidden
className="size-4 shrink-0 text-current/55"
/>
<span className="truncate font-mono text-[13px]">{d.branch}</span>
</span>
<span className="flex min-w-0 items-center gap-2.5">
<GitCommitHorizontal
aria-hidden
className="size-4 shrink-0 text-current/55"
/>
<span className="shrink-0 font-mono text-[13px]">
{d.commit.sha.slice(0, 7)}
</span>
<span className="truncate" title={d.commit.message}>
{d.commit.message}
</span>
</span>
</dd>
</div>
</dl>
)
}
/** Share: the deployment's own address (`unique`), to copy: it serves this build
* whatever is deployed after it. */
function SharePopover({ host }: { host: string }) {
const url = `https://${host}`
return (
<Popover>
<PopoverTrigger
render={
<Button variant="outline">
<Share aria-hidden />
Share
</Button>
}
/>
<PopoverContent align="end" className="w-96 gap-3">
<div className="flex flex-col gap-1">
<PopoverTitle>Share this deployment</PopoverTitle>
<PopoverDescription>
Its own address: it serves this build, whatever is deployed after
it.
</PopoverDescription>
</div>
<div className="flex min-w-0 items-center gap-1 rounded-md py-0.5 pr-0.5 pl-2.5 ring-1 ring-current/15">
<span className="min-w-0 flex-1 truncate font-mono text-xs">
{url}
</span>
<Copy value={url} />
</div>
</PopoverContent>
</Popover>
)
}
/** Visit: the first domain serving it, every other under the chevron; there once it
* is live. */
function Visit({ deployment: d }: { deployment: Deployment }) {
const first = firstDomains(d.domains)[0] as Domain
const live = d.status === "ready"
return (
<ButtonGroup data-slot="deployment-visit">
{live ? (
<Button
render={
<a
href={`https://${first.host}`}
target="_blank"
rel="noreferrer"
/>
}
>
Visit
</Button>
) : (
<Button disabled>Visit</Button>
)}
<DropdownMenu>
<DropdownMenuTrigger
render={
<Button size="icon" aria-label="every domain" disabled={!live}>
<ChevronDown />
</Button>
}
/>
<DropdownMenuContent className="min-w-64">
<DropdownMenuLabel>Visit</DropdownMenuLabel>
{d.domains.map((domain) => (
<DropdownMenuLinkItem
key={domain.host}
href={`https://${domain.host}`}
target="_blank"
rel="noreferrer"
>
{React.createElement(DOMAIN_MARK[domain.kind], {
"aria-hidden": true,
})}
<span className="truncate">{domain.host}</span>
</DropdownMenuLinkItem>
))}
</DropdownMenuContent>
</DropdownMenu>
</ButtonGroup>
)
}
// ── the steps ────────────────────────────────────────────────────────────────────
/** A step's state at the end of its row: what Vercel draws there. */
export function StepMark({
state,
className,
}: {
state: StepState
className?: string
}) {
const label = {
passed: "done",
running: "running",
pending: "waiting",
failed: "failed",
skipped: "skipped",
}[state]
if (state === "running")
return <Spinner size="lg" label={label} className={className} />
const look = {
// Filled discs, their mark cut out of them in the ground's colour.
passed: "fill-tone-info text-background",
failed: "fill-tone-bad text-background",
pending: "text-current/45",
skipped: "text-current/35",
}[state]
const Mark = {
passed: CircleCheck,
failed: CircleX,
pending: Clock,
skipped: CircleMinus,
}[state]
return (
<Mark
role="img"
aria-label={label}
data-slot="deployment-step"
data-state={state}
className={cn("size-5 shrink-0", look, className)}
/>
)
}
export type DeploymentStepProps = {
/** The section's name, unique among the steps: what `defaultOpen` names. */
value: string
title: React.ReactNode
/** Its state, as the host reports it. None, no mark. */
state?: StepState
/** Beside the mark: the step's own controls and numbers. */
aside?: React.ReactNode
/** Its content under the title, aligned with it; `false`, from the row's edge. */
inset?: boolean
children: React.ReactNode
ref?: React.Ref<HTMLDivElement>
}
/** One step of the deployment, a section that opens in place. */
export function DeploymentStep({
value,
title,
state,
aside,
inset = true,
children,
ref,
}: DeploymentStepProps) {
useDetails("DeploymentStep")
return (
<AccordionItem
value={value}
ref={ref}
data-slot="deployment-details-step"
className="scroll-mt-4 border-current/10"
>
<AccordionTrigger
chevron="start"
className={ROW_TITLE}
aside={
(aside || state) && (
<div className="flex items-center gap-3 pr-4">
{aside}
{state && <StepMark state={state} />}
</div>
)
}
>
{title}
</AccordionTrigger>
<AccordionContent
className={cn("px-4 pb-4", inset ? "pl-11" : "text-current")}
>
{children}
</AccordionContent>
</AccordionItem>
)
}
/** The build's step: its log, and its trace beside it once asked for. Only for a
* build the host saw (`deployment.build`). */
export function DeploymentBuild({
defaultRunSummary = false,
}: {
/** The build's trace shown beside its log at first (Run Summary pressed). */
defaultRunSummary?: boolean
}) {
const { deployment: d, took, opening, build } = useDetails("DeploymentBuild")
const state = buildState(d)
const counts = buildCounts(d)
const { lines, spans } = d.build as NonNullable<Deployment["build"]>
const [floor, setFloor] = React.useState<LogLevel>("trace")
const [traced, setTraced] = React.useState(defaultRunSummary)
const [span, setSpan] = React.useState<string | null>(null)
const [line, setLine] = React.useState<string | null>(null)
const toFloor = (level: LogLevel) => {
setFloor((was) => (was === level ? "trace" : level))
opening(BUILD)
}
const spanOf = (id: string) => lines.find((l) => l.id === id)?.span?.id
// A trace needs a span with a length to lay an axis along.
const drawable =
spans.length > 0 &&
Math.max(...spans.map((x) => x.to)) > Math.min(...spans.map((x) => x.from))
const log = (
<Log
lines={lines}
label={`${d.project.name}'s build log`}
minLevel={floor}
onMinLevelChange={setFloor}
selected={line}
onSelectedChange={(id) => {
setLine(id)
if (id) setSpan(spanOf(id) ?? null)
}}
span={span}
onSpanChange={(id) => {
setSpan(id)
setTraced(true)
}}
className="h-full"
/>
)
return (
<DeploymentStep
value={BUILD}
ref={build}
title="Build Logs"
state={state}
inset={false}
aside={
<>
{counts.warnings > 0 && (
<Button
variant="outline"
corners="pill"
pressed={floor === "warn"}
aria-label={`${counts.warnings} warnings: show warnings and errors only`}
onClick={() => toFloor("warn")}
className="px-3"
>
<TriangleAlert aria-hidden className={TONE_WORDS.warn} />
<span className="font-mono tabular-nums">{counts.warnings}</span>
</Button>
)}
{counts.errors > 0 && (
<Button
variant="outline"
corners="pill"
pressed={floor === "error"}
aria-label={`${counts.errors} errors: show errors only`}
onClick={() => toFloor("error")}
className="px-3"
>
<CircleX aria-hidden className={TONE_WORDS.bad} />
<span className="font-mono tabular-nums">{counts.errors}</span>
</Button>
)}
{spans.length > 0 && (
<Button
variant="outline"
pressed={traced}
onClick={() => {
setTraced((was) => !was)
opening(BUILD)
}}
className="@max-xl/details:hidden"
>
<ChartNoAxesGantt aria-hidden />
Run Summary
</Button>
)}
{took !== null && (
<span className={cn(META, "@max-md/details:hidden")}>
{durationText(took)}
</span>
)}
</>
}
>
{!traced ? (
<div className="h-[28rem]">{log}</div>
) : (
<div className="grid h-[44rem] grid-rows-2 gap-4 @4xl/details:h-[30rem] @4xl/details:grid-cols-[3fr_2fr] @4xl/details:grid-rows-1">
<div className="min-h-0 min-w-0">
{drawable ? (
<Trace
spans={spans}
label={`${d.project.name}'s build`}
visibleRows="fill"
selected={span}
onSelectedChange={setSpan}
lines={lines}
line={line}
onLineChange={setLine}
className="h-full p-0"
/>
) : (
<p className="m-0 grid h-full place-items-center text-current/55">
The build has not started a step yet.
</p>
)}
</div>
<div className="min-h-0 min-w-0 border-current/10 @4xl/details:border-l @4xl/details:pl-4">
{log}
</div>
</div>
)}
</DeploymentStep>
)
}
const KIND_WORDS: Record<ResourceKind, string> = {
function: "Functions",
static: "Static Assets",
middleware: "Middleware",
}
const KIND_MARK: Record<ResourceKind, typeof Globe> = {
function: SquareFunction,
static: FileCode,
middleware: Route,
}
/** What the build put out, by kind. Only for a deployment whose output the host
* read (`deployment.resources`). */
export function DeploymentSummary() {
const { deployment: d } = useDetails("DeploymentSummary")
const state = outputState(d)
const resources = d.resources as NonNullable<Deployment["resources"]>
const [kind, setKind] = React.useState<ResourceKind | "all">("all")
const shown = resources.filter((r) => kind === "all" || r.kind === kind)
return (
<DeploymentStep
value="summary"
title="Deployment Summary"
state={state}
aside={
resources.length > 0 && (
<DropdownMenu>
<DropdownMenuTrigger
render={
<Button
variant="outline"
pressed={kind !== "all"}
icon={<ListFilter aria-hidden />}
className="@max-md/details:hidden"
>
{kind === "all" ? "Resources" : KIND_WORDS[kind]}
</Button>
}
/>
<DropdownMenuContent className="min-w-48">
<DropdownMenuRadioGroup
value={kind}
onValueChange={(v) => setKind(v as ResourceKind | "all")}
>
<DropdownMenuRadioItem value="all">
All resources
</DropdownMenuRadioItem>
{RESOURCE_KINDS.filter((k) =>
resources.some((r) => r.kind === k),
).map((k) => (
<DropdownMenuRadioItem key={k} value={k}>
{KIND_WORDS[k]}
</DropdownMenuRadioItem>
))}
</DropdownMenuRadioGroup>
</DropdownMenuContent>
</DropdownMenu>
)
}
>
{shown.length === 0 ? (
<p className="m-0 text-current/55">
{d.status === "ready"
? "Nothing of this kind."
: "The build has put nothing out yet."}
</p>
) : (
<div className="flex flex-col gap-4">
{RESOURCE_KINDS.map((k) => {
const of = shown.filter((r) => r.kind === k)
if (of.length === 0) return null
const Mark = KIND_MARK[k]
return (
<section key={k} className="flex flex-col gap-1.5">
<h4 className="m-0 font-normal text-current/55">
{KIND_WORDS[k]}{" "}
<span className="font-mono text-xs tabular-nums">
{of.length}
</span>
</h4>
<ul className="m-0 flex list-none flex-col gap-1 p-0">
{of.map((r) => (
<li
key={r.name}
className="flex min-w-0 items-center gap-2.5 leading-6"
>
<Mark
aria-hidden
className="size-4 shrink-0 text-current/55"
/>
<span className="truncate font-mono text-[13px]">
{r.name}
</span>
{r.detail && (
<span className="ml-auto shrink-0 text-current/55 text-xs">
{r.detail}
</span>
)}
</li>
))}
</ul>
</section>
)
})}
</div>
)}
</DeploymentStep>
)
}
/** What ran on it once built. Only for a deployment the host runs checks on
* (`deployment.checks`). */
export function DeploymentChecks() {
const { deployment: d } = useDetails("DeploymentChecks")
const state = checksState(d)
const checks = d.checks as NonNullable<Deployment["checks"]>
return (
<DeploymentStep value="checks" title="Deployment Checks" state={state}>
{checks.length === 0 ? (
<p className="m-0 text-current/55">
{d.status === "ready"
? "No checks run on this deployment."
: "Checks run once it is built."}
</p>
) : (
<ul className="m-0 flex list-none flex-col gap-2 p-0">
{checks.map((c) => (
<li key={c.name} className="flex min-w-0 items-center gap-2.5">
<StepMark state={c.state} className="size-4" />
<span className="truncate">{c.name}</span>
{c.detail && (
<span className="ml-auto shrink-0 text-current/55 text-xs">
{c.detail}
</span>
)}
</li>
))}
</ul>
)}
</DeploymentStep>
)
}// A DEPLOYMENT, as a host's dashboard shows one: what was built (a project, a commit on
// a branch, by someone), where it went (production or a preview, the current one or
// not), how it stands (queued, building, ready, error, canceled), when, how long it
// took, the domains serving it, and what else the host knows of it: a picture, its
// build (the lines the build wrote and the spans it ran, lib/telemetry, so the build's
// log and its trace link both ways), what it put out, the checks run on it, the
// settings it recommends. Framework-free.
//
// known every optional part is a fact the host has or has not: absent means
// the host does not know it, and nothing that draws a deployment makes
// one up. An ended deployment whose build its host never saw (an upload
// built somewhere else) has no `build`, no `started`, no `duration`
// instants ms since the epoch: `created` (pushed), `started` (the build began),
// every build line's `at` and span's `from` and `to`
// duration ms, written once the build has ended; while it builds, the running
// time is a calculation (`elapsed`), never a field
// counts a build's warnings and errors are counted from its lines (`buildCounts`),
// never stored beside them
//
// The facts are asserted (`assertDeployment`, `assertDeployments`): a deployment that
// says it is ready without a duration, or building with one, is a confused program, and
// it screams where the data enters, not three components later.
import type { LogLine, TraceSpan } from "@/registry/base-nova/lib/telemetry"
export const DEPLOYMENT_STATES = [
"queued",
"building",
"ready",
"error",
"canceled",
] as const
/** How a deployment stands: waiting for a builder, building, live, failed, stopped. */
export type DeploymentState = (typeof DEPLOYMENT_STATES)[number]
export const ENVIRONMENTS = ["production", "preview"] as const
export type Environment = (typeof ENVIRONMENTS)[number]
/** Whoever wrote the commit: a name, and their picture's URL. */
export interface Author {
name: string
avatar?: string
}
export interface Project {
name: string
/** The project's picture (its favicon), a URL. Without one, the default mark. */
icon?: string
}
export interface Commit {
/** The commit's hash, at least its first seven hex digits. */
sha: string
/** Its message's first line. */
message: string
author: Author
}
/** A host the deployment answers on: the project's own (`custom`), the branch's
* alias that follows its latest deployment (`branch`), or this deployment's own URL
* that never moves (`unique`). */
export interface Domain {
host: string
kind: "custom" | "branch" | "unique"
}
/** What a step after the build reports (a check, a domain being assigned). */
export type StepState = "pending" | "running" | "passed" | "failed" | "skipped"
/** A check run on the deployment once built (an end-to-end suite, a lighthouse run). */
export interface DeploymentCheck {
name: string
state: StepState
/** One line on how it went or what it waits for. */
detail?: string
}
/** A setting the platform suggests changing, and why. */
export interface Recommendation {
title: string
detail: string
}
export const RESOURCE_KINDS = ["function", "static", "middleware"] as const
export type ResourceKind = (typeof RESOURCE_KINDS)[number]
/** What the build put out: a function, a static asset, the middleware. */
export interface Resource {
kind: ResourceKind
/** Its route or path ("/api/og", "/_next/static/chunks/…"). */
name: string
/** One line of what it is: its region and runtime, its size. */
detail?: string
}
export interface Deployment {
/** Unique among the deployments shown ("FF9zVMDas"). */
id: string
project: Project
commit: Commit
branch: string
environment: Environment
/** The deployment production serves now. Only a production deployment can be. */
current?: boolean
status: DeploymentState
/** When it was created, ms since the epoch. */
created: number
/** When its build began: absent while queued, present from building on, and absent
* with `duration` on an ended deployment whose build the host never saw. */
started?: number
/** How long its build took, ms: present once it has ended (ready, error), absent
* while queued or building, and absent with `started` when the build is unknown. */
duration?: number
/** The hosts serving THIS deployment now. An older deployment the project's own and
* the branch's hosts moved on from keeps only its own (`unique`), when it has one. */
domains: readonly Domain[]
/** A picture of the deployed page, a URL. */
preview?: string
/** What its build wrote and ran, on the same clock as `created`; absent when the
* build ran where the host could not see it. */
build?: {
lines: readonly LogLine[]
spans: readonly TraceSpan[]
}
recommendations?: readonly Recommendation[]
resources?: readonly Resource[]
checks?: readonly DeploymentCheck[]
}
/** The deployment's facts, checked; throws naming the first that is wrong. */
export function assertDeployment(d: Deployment): void {
const at = `deployment "${d.id}"`
if (!d.id) throw new Error("deployment: an id is required")
if (!DEPLOYMENT_STATES.includes(d.status))
throw new Error(`${at}: no state "${d.status}"`)
if (!ENVIRONMENTS.includes(d.environment))
throw new Error(`${at}: no environment "${d.environment}"`)
if (d.current && d.environment !== "production")
throw new Error(`${at}: only a production deployment can be current`)
if (!/^[0-9a-f]{7,40}$/.test(d.commit.sha))
throw new Error(`${at}: commit "${d.commit.sha}" is no hash`)
if (!Number.isFinite(d.created))
throw new Error(`${at}: created is no instant (${d.created})`)
const begun = d.started !== undefined
const ended = d.duration !== undefined
if (d.status === "queued" && (begun || ended))
throw new Error(`${at}: queued, yet its build has begun`)
if (d.status === "building" && !begun)
throw new Error(`${at}: building, with no instant it started`)
if (d.status === "building" && ended)
throw new Error(`${at}: building, yet it has a duration`)
if ((d.status === "ready" || d.status === "error") && begun !== ended)
throw new Error(
`${at}: ${d.status}, with a ${begun ? "start but no duration" : "duration but no start"} (both, or neither when the build is unknown)`,
)
if (begun && (d.started as number) < d.created)
throw new Error(`${at}: started before it was created`)
if (ended && !((d.duration as number) >= 0))
throw new Error(`${at}: duration ${d.duration} is no length`)
if (!d.build) {
if (begun || d.status === "queued" || d.status === "building")
throw new Error(
`${at}: ${d.status}${begun ? ", its build begun" : ""}, with no build: only an ended build the host never saw has none`,
)
return
}
if ((d.status === "ready" || d.status === "error") && !begun)
throw new Error(
`${at}: ${d.status} with a build but no start: a build the host never saw has no \`build\``,
)
const spans = new Set(d.build.spans.map((s) => s.id))
for (const line of d.build.lines)
if (line.span && !spans.has(line.span.id))
throw new Error(
`${at}: build line "${line.id}" names span "${line.span.id}", which the build has not`,
)
}
/** Every deployment checked, and their ids unique. */
export function assertDeployments(ds: readonly Deployment[]): void {
const ids = new Set<string>()
for (const d of ds) {
if (ids.has(d.id)) throw new Error(`deployment: two are "${d.id}"`)
ids.add(d.id)
assertDeployment(d)
}
}
/** How many of the build's lines are warnings and errors; none for a build the host
* never saw. */
export function buildCounts(d: Deployment): {
warnings: number
errors: number
} {
let warnings = 0
let errors = 0
for (const line of d.build?.lines ?? []) {
if (line.level === "warn") warnings++
else if (line.level === "error") errors++
}
return { warnings, errors }
}
/** How long the build took, or has taken so far at `now` while it builds; null while
* queued, for a canceled one that never began, and for a build the host never saw. */
export function elapsed(d: Deployment, now: number | null): number | null {
if (d.duration !== undefined) return d.duration
if (d.status !== "building" || d.started === undefined || now === null)
return null
return Math.max(0, now - d.started)
}
/** A build's length as the dashboard says it: "42s", "1m 31s", "1h 4m". */
export function durationText(ms: number): string {
const s = Math.floor(ms / 1000)
if (s < 60) return `${s}s`
const m = Math.floor(s / 60)
if (m < 60) return `${m}m ${s % 60}s`
return `${Math.floor(m / 60)}h ${m % 60}m`
}
/** The choices a list narrows by; unset, everything. */
export interface DeploymentFilter {
author?: string
environment?: Environment
status?: DeploymentState
}
export type FilterKey = keyof DeploymentFilter
export function filterDeployments(
ds: readonly Deployment[],
f: DeploymentFilter,
): Deployment[] {
return ds.filter(
(d) =>
(f.author === undefined || d.commit.author.name === f.author) &&
(f.environment === undefined || d.environment === f.environment) &&
(f.status === undefined || d.status === f.status),
)
}
/** A value a filter can take, and how many deployments have it. */
export interface FilterChoice<V extends string = string> {
value: V
count: number
}
/** What each filter can be set to, read from the deployments themselves (only what
* is there, most common first), so a choice never finds nothing. */
export function filterChoices(ds: readonly Deployment[]): {
author: FilterChoice[]
environment: FilterChoice<Environment>[]
status: FilterChoice<DeploymentState>[]
} {
const tally = <V extends string>(values: V[], order?: readonly V[]) => {
const counts = new Map<V, number>()
for (const v of values) counts.set(v, (counts.get(v) ?? 0) + 1)
return [...counts]
.map(([value, count]) => ({ value, count }))
.sort((a, b) =>
order
? order.indexOf(a.value) - order.indexOf(b.value)
: b.count - a.count || a.value.localeCompare(b.value),
)
}
return {
author: tally(ds.map((d) => d.commit.author.name)),
environment: tally(
ds.map((d) => d.environment),
ENVIRONMENTS,
),
status: tally(
ds.map((d) => d.status),
DEPLOYMENT_STATES,
),
}
}
// ── The steps a details page reports, each from the part it reports on. A step
// exists only for a part the host knows: no state is read off the status alone for a
// part that is not there.
/** The build's step: how the deployment stands, for a build the host saw. */
export function buildState(d: Deployment): StepState {
if (!d.build) throw new Error(`deployment "${d.id}": no build to report`)
return d.status === "queued"
? "pending"
: d.status === "building"
? "running"
: d.status === "ready"
? "passed"
: d.status === "error"
? "failed"
: "skipped"
}
/** What the build put out (`resources`): there once it is ready, never for one that
* failed or was stopped. */
export function outputState(d: Deployment): StepState {
if (!d.resources) throw new Error(`deployment "${d.id}": no output to report`)
return d.status === "ready"
? "passed"
: d.status === "error" || d.status === "canceled"
? "skipped"
: "pending"
}
/** The checks, from the checks themselves: failed if one failed, running if one
* runs, passed once none waits. */
export function checksState(d: Deployment): StepState {
const checks = d.checks
if (!checks) throw new Error(`deployment "${d.id}": no checks to report`)
if (d.status === "error" || d.status === "canceled") return "skipped"
if (checks.some((c) => c.state === "failed")) return "failed"
if (checks.some((c) => c.state === "running")) return "running"
return checks.length > 0 && checks.every((c) => c.state !== "pending")
? "passed"
: "pending"
}
